Laser Cutting Machine In Ahmedabad
Sigma Mechotronics Pvt. Ltd. is an ISO & CE Certified manufacturer of fiber laser cutting machines, with its head office at Odhav and its manufacturing plant at Bakrol. For fabricators looking for a laser cutting machine in Ahmedabad, we design and build fiber laser cutting machines for sheet metal, plate, and pipe and tube cutting, in five configurations for different production needs. Our machines cut mild steel, stainless steel and aluminium, and brass and copper with a cutting head protected against back-reflection.
Our fiber laser cutting machines are available from 1.5 kW to 20 kW, so the range covers both thin sheet work and heavy plate cutting, and the dedicated tube machine runs from 1.5 kW to 12 kW. The frame, bed and structure of every machine are made at our own plant, and our own technical team installs it at your premises and then trains your operators free of charge for 1 to 7 days. After-sales service is handled directly by our team, without a dealer or agent, and backed by 24/7 support.
What a Laser Cutting Machine Does on the Shop Floor
A fiber laser cutting machine focuses a laser beam onto sheet or plate, melts a narrow line through it and blows the melt away with assist gas. There is no punch, no die and no tool change: a new part is simply a new drawing file. That is why one machine can cut a bracket for one customer in the morning and a signage panel for another in the afternoon.
Which Ahmedabad Industries Use Laser Cutting Machines
Almost every metal-working trade in the city now runs fiber laser cutting. Each uses it for a different reason:
- Sheet metal and job-work fabrication: brackets, mounting plates, frames and enclosure blanks, with a job mix that changes daily.
- Automotive and auto-ancillary units: repeat components where every part in a batch has to match.
- Electrical panels and switchgear: accurate cut-outs and holes in panel and enclosure sheet.
- Structural steel fabrication: thicker plate, where both cutting speed and edge quality count.
- Elevators, racking and storage: high-volume repeat parts, well suited to an auto pallet changer.
- Stainless kitchen and food equipment: clean, weld-ready edges with no grinding afterwards.
- Railings, furniture and architectural metalwork: sheet and tube work, often on the same machine.
- Signage and display: fine lettering and detail cut directly from the design file.
Materials, Typical Parts and the Right Assist Gas
| Material | Typical Parts | Assist Gas and Setup |
|---|---|---|
| Mild and carbon steel | Brackets, base plates, gussets, panel blanks | Oxygen for fast, economical cuts; nitrogen where edges go straight to welding or painting |
| Stainless steel | Kitchen equipment, food machinery, enclosures | Nitrogen for a bright, oxide-free edge |
| Aluminium | Signage, light panels, covers | Nitrogen, with a cutting head rated for reflective metal |
| Brass and copper | Electrical parts, decorative work | A cutting head protected against back-reflection |
| Tube and pipe | Railings, furniture frames, structures | A tube attachment or a dedicated tube cutting machine |
How to Match the Machine to Your Work
Your industry is only the starting point. Two shops in the same trade can need very different machines, and three questions decide it.
What Thickness Do You Cut Most Often?
Size the machine for the thickness you cut every week, not the thickest job you take twice a year. That single choice sets the laser power, and power is the biggest part of the price.
Is Your Work Job-Work or Repeat Batches?
Changing one-off jobs suit an open single-pallet machine. Long runs of the same part suit an auto pallet changer, which loads the next sheet while the current one cuts.
Is Tube Occasional or Your Main Product?
Occasional tube work fits a flat bed with a tube attachment. If tube and pipe are your main business, a dedicated tube cutting machine pays off.
| Configuration | Suited To |
|---|---|
| Single pallet, open type | Mixed job work with changing parts |
| Auto pallet changer, open type | Repeat batches and volume production |
| Close body | Enclosed cutting with built-in dust and fume extraction |
| Flat bed with tube and pipe attachment | Sheet work plus occasional tube |
| Dedicated tube cutting machine | Tube, pipe and profiles as the main product |
Basic Technical Data
Basic technical data for Sigma’s 1.5 kW and 3 kW fiber laser cutting machines on a 3200 x 1600 mm table:
| Item | 1.5 kW | 3 kW |
|---|---|---|
| Laser power | 1500 W | 3000 W |
| Wavelength | 1064 nm | 1064 nm |
| Working table | 3200 x 1600 mm | 3200 x 1600 mm |
| X / Y / Z-axis travel | 1600 / 3200 / 125 mm | 1600 / 3200 / 125 mm |
| Maximum linked speed | 85 m/min | 80 m/min |
| Maximum acceleration | 0.5 G | 1 G |
| X/Y positioning accuracy | ±0.05 mm | ±0.05 mm |
| X/Y repositioning accuracy | ±0.03 mm | ±0.03 mm |
| Maximum load | 1000 kg | 1500 kg |
| Machine weight (approx.) | 3 to 3.5 tonnes | 4 to 5 tonnes |
| Power demand | 380 V, up to 16 kW | 380 V, up to 30 kW |
Standard beds run from 3200 x 1600 mm up to 6500 x 2500 mm, and a custom bed can be engineered to your drawing. See every configuration on Sigma’s laser cutting machines page.
Need data for another laser power? Message Sigma on WhatsApp today and ask for a quotation. It comes with the full technical details and price for the power and bed size you need.
Features That Keep the Machine Cutting
- Auto edge finding: the machine reads the sheet’s position and angle, so nobody squares it by hand.
- Fly cutting: rows of holes are cut in one continuous pass, saving head travel on repetitive parts.
- Anti-collision cutting head: protects the head from parts that tip up after cutting.
- Auto height following: keeps the nozzle-to-sheet gap constant, even on slightly uneven sheet.
- Drawing import and nesting: the CNC takes DXF and DWG files and nests parts to reduce scrap.
Common Mistakes When Choosing a Machine
- Buying for the industry label, not the parts. “Sheet metal fabrication” covers everything from thin signage blanks to thick structural plate. Describe your actual parts.
- Mentioning tube work after the order. If tube is even occasional, say so at enquiry stage; it decides the configuration.
- Undersizing fume extraction. Size it for the dirtiest material you cut, such as galvanised or painted sheet.
- Paying for power you will rarely use. A machine sized for the occasional thick plate adds cost without adding useful output.
Checklist Before You Ask for a Quotation
- Materials you cut, and the thickness you cut most often
- Whether brass, copper or aluminium is part of the mix
- Largest regular sheet or part size
- Whether tube or pipe work is occasional or regular
- Sheets or parts per shift
- Floor space and crane or forklift access
- Three-phase power, compressed air and extraction space
Why Buying From an Ahmedabad Manufacturer Helps
Sigma designs and builds its fiber laser cutting machines at its own plant in Bakrol: the frame, bed and structure are made there, the components are selected and integrated by Sigma’s engineers, and every build is inspected stage by stage.
- Free installation and training: our own team installs the machine, sets cutting parameters on your material and trains your operators for 1 to 7 days.
- Direct support: after-sales service comes from the people who built the machine, with 24/7 support and spares held in India.
- Warranty: a 2-years warranty on manufacturing defects, with annual maintenance contracts after that.
- Free demo: see a machine working before you buy.
- Registered and certified: ISO & CE Certified, MSME and GST Registered, with a GST tax invoice under your GSTIN.
Read more on how Sigma builds and supports its machines.
Head Office
No. 22, Bileshwar Industrial Estate, Opposite GVMM, Odhav Industrial Estate, Odhav, Ahmedabad, Gujarat 382415
Manufacturing Plant
Plot No. 58-59-60, Gopal Charan Industrial Hub, Bakrol, Ahmedabad, Gujarat
Frequently Asked Questions
Which industries in Ahmedabad use laser cutting machines?
Sheet metal job work, automotive components, electrical panels, structural steel, elevators and racking, stainless kitchen equipment, railings and furniture, and signage. One machine handles both one-off jobs and repeat batches.
Can one laser cutting machine cut both sheet and tube?
Yes, a flat bed with a tube and pipe attachment cuts sheet plus occasional round, square and rectangular tube. If tube is your main product, a dedicated tube cutting machine is the better fit.
What metals can a fiber laser cutting machine cut?
Mild steel, stainless steel and aluminium as standard, and brass and copper with a cutting head protected against back-reflection. The thickness it can cut rises with laser power.
Is installation and training free in Ahmedabad?
Yes. Sigma’s own team installs and commissions the machine at your premises and trains your operators free of charge for 1 to 7 days, with 24/7 support after that.
How do I get the price of a laser cutting machine in Ahmedabad?
Message Sigma on WhatsApp at +91 99090 26467 with your material, thickness, sheet size and the laser power you need. You will get a quotation with the full technical details for that configuration.
Final Thoughts
A laser cutting machine earns its place in so many Ahmedabad workshops for one reason: no tooling change between jobs. Choose it by the metal and thickness you cut every week, not by your industry label, and buy it from a manufacturer that installs, trains and supports it on your floor.
Talk to an Ahmedabad Manufacturer Directly
Tell Sigma your material, thickness, part size and production volume so the suitable machine configuration can be discussed. Installation and 1 to 7 days of operator training are free, and you can book a free demo.
